Model 4010 Radio Dispatch Console

SKU: 4010 Category:


Portable and Self-Contained Radio Dispatch Console
The Model 4010 (Desktop) and Model 4010R (Rackmount) Radio Consoles are self-contained, single position radio console systems which accommodates up to 12 radio channels and 2 telephone lines. The units are compact and versatile.

The Model 4010’s modular design and programmability allow the unit to be configured to meet a wide range of public safety, government, institutional and industrial applications.

The Model 4010 is rigidly constructed, and is rated for continuous 7 day/24 hour applications with a proven track record of field reliability under the most demanding conditions. It is also suitable for portable applications, such as temporary or mobile Control Centers.

The Model 4010 has programmable function buttons for functions such as group call, channel select, channel mute, and channel patch. There is an integral keypad and LCD to display incoming calls. Two separate speakers are provided to allow the operator to hear selected and monitored audio, with volume levels adjusted on each individual channel. The operator options include a handset, gooseneck or desk microphone, headset and footswitch. Base station control is local or remote, using tone remote control 2970 Hz keytone, DC or E&M.
